Description
CMT Orange Tools, 289-Series, 289.100.20H, 289-Series, 100 x 10+10 x 2 Conical Scoring Saw Blade
Application: For chip-free scoring on plastic-laminated panels.
Machines: Horizontal and vertical sizing machines equipped with scoring device not allowing for cutting depth adjustment.
Material: Single or double-sided plastic-laminated panels, MDF.
Diameter mm 100
Number of cutting edges 10+10
Bore Diameter mm 20
Pin hole 2/3,1 – 3,8/32
Type of grind FLAT
Hook angle 12°
Kerf thickness mm 2,8-3,6
Teeth height mm 6-10
CHROMIUM ISO grade KCR05
Hardness (HV10) 2.150
Transverse rupture strength (N/mm2) 2.500
