Description
These Full Mortise Standard Weight Two Knuckle Ball Bearing Hinges are for use on medium weight doors or doors requiring average frequency service. The hinges are secure – the door cannot be lifted off when in closed position. They are available in 4.5″ x 4″ and 4.5″ x 4.5″ sizes, and come in Satin Chrome, Stainless Steel, and Primed for Painting finishes.
Product Specifications:
- Full Mortise Standard Weight Two Knuckle Ball Bearing Hinges
- Sizes Available:
- 4-1/2″ Inch x 4″ Inch
- Height: 4-1/2″
- Width: 4″
- Material Gauge: .134 ± .005
- 4-1/2″ Inch x 4-1/2″ Inch
- Height: 4-1/2″
- Width: 4-1/2″
- Material Gauge: .134 ± .005
- Finishes Available: Satin Chrome, Stainless Steel, Primed for Painting
- Handing Available: Right, Left
- Material: Steel (Satin Chrome & Primed for Painting); Stainless Steel
- 4.5″ Standard Screw Size: FHMS – 12-24 x 1/2”; FHWS – 12 x 1-1/4”
- For use on medium weight doors or doors requiring average frequency service
- Secure: Door cannot be lifted off when in closed position
- Concealed Delrin bearing takes both vertical and lateral loads
- All hinges are ANSI template
- Manufactured to close tolerances and meet all specifications and requirements set by the American National Standards Institute (ANSI)
- Hinge Swaging: A standard swaging of our standard weight full mortise hinge when closed to parallel position provides a 1/16” clearance between leaves
- Template
- Screws included
- Sold as 3 Pack
