Description
This Inset Receding Cabinet Sliding Door System is for use with upward-opening cabinet doors. It features an adjustable soft-closing speed which prevents slamming. It is available in 14″, 16″, 19″, and 24″ tracks.
Product Specifications:
- Inset Receding Cabinet Sliding Door System
- Soft close
- Finish: Nickel
- Materials: Slide and Hinge – Steel; Soft-Down Stay – Zinc Alloy
- Track Lengths Available:
- 14″ Inch: Travel Length 10-9/16″
- 16″ Inch: Travel Length 12-9/16″
- 19″ Inch: Travel Length 15-9/16″
- 24″ Inch: Travel Length 20-9/16″
- Door Thicknesses Available: 19/32″ to 13/16″ (15-20mm), 11/16″ to 1-3/16″ (18-30mm)
- Maximum Door Widths Available: 23-5/8” Inch, 47-1/4″ Inch
- *See picture below for detailed size chart
- For upward-opening cabinet doors
- Soft-close feature prevents slamming
- Adjustable Soft-closing speed
- Door pockets into the cabinet to get out of the way when opened
- NSDX soft-down stay successfully passed 30,000 open/close private cycles test
- CA Prop 65 Compliant: No
- NSF Compliant: No
- ROHS Compliant: No
- Includes either 1 or 2 NSDX soft-down stays depending on kit selection (see size chart)
- Includes fasteners: Pan head screw with captive washer – M4 X 6MM, Truss Head Screw – M4 X 5MM, Bind Head Tapping Screw – 3.5 X 16MM, Raised Countersunk Head Tapping Screw – 3.5 X 16MM
- Sold as kit
