Description
Description:
- GVWR: 5,000 lbs
- Width: 83″
- Length: 14′
Standard Features:
- GVWR: 5,000 lbs.
- Bed Width(s): 78″, 83”
- Lengths Available: 10′, 12′, 14′
- Axle: 5000 LB Straight, Dexter E-Z Lube
- Tires: 225/R15 LRD Radial Tires, Mod Wheel
- Spare Tire Mount
- Axle Type: Idler Axle
- Springs: Four Leaf Eye-To-Eye Springs
- Jack: 2,000 LB Jack
- Coupler: 5K, 2″ A-Frame Coupler
- Fenders: 9.5″ X 36″ Smooth Jeep Style Fenders
- Chassis: 4” Channel Chassis
- Tongue: 4” Structural Channel Wrapped Tongue
- Crossmembers: 2″ X 2″ Angle Crossmembers, 24” On Center
- Decking: Treated Pine Decking
- Wiring: Industrial Grade Sealed Wiring Harness, LED Lights
- Finish: Sand Blasted, Degreased, Acid Washed, Sealer Rinsed, Sherwin Williams Powder Coat for a High Gloss & Protective Finish
Options:
- Tire Options:
- 225/R15 LRD RADIAL, Silver Mod Wheels
- 225/R15 LRD RADIAL, Black Mod Wheels
- Jack Options:
- 2,000 LB Set Back Jack
- 7,000 LB Dropleg Set Back Jack
- Tail Options:
- 30″ Tube Gate, 6GA Expanded (One Spring Standard)
- 48″ Tube Gate, 6GA Expanded (Two Springs Standard)
- 2′ Wood Dovetail
- Side Mount ATV Ramps [14′ Length Only]
- 60″ X 48″ Tube Side Gate, 6GA Expanded [12′ & 14′ Lengths]
- Top Rail Options:
- 2″ X 2″ Angle Top Rail & Uprights
- 2 1/2″ X 1 1/2″ Tube Top Rail & 2″ X 2″ Tube Uprights
- Side Options:
- 20″ Removable Three Board Sides
- 23″ V-Crimped Solid Metal Sides
- Other Options:
- Radial Spare Tire and Wheel Mounted on Trailer
